Ground Joint-GL 2-Way Stopcocks | BOLA
A
B
A
B
A
B
A
B
| Chemical resistance: | +++ universal |
|---|---|
| Material: | PTFE |
| Pressure: | 6 bar |
| Temperature resistance: | from 0°C to +110°C |
| Vacuum: | suitable |
FDAFDA conform:
All parts coming into contact with the fluid are from materials that correspond to FDA requirements. A certificate of conformity is included with each shipment.
All parts coming into contact with the fluid are from materials that correspond to FDA requirements. A certificate of conformity is included with each shipment.
Technical information
Material Safety Data Sheets
You may also like these products
|
Bore dia. [mm] |
Bore shape [stopcock] |
Connecting thread [GL] |
External dimensions [L / D / H mm] |
For ground [joint NS] |
Type | Unit price | Product number | Select the quantity for an offer or order and place it in the shopping cart |
|---|
Product information "Ground Joint-GL 2-Way Stopcocks | BOLA"
Product description
Ground joint 2-way-stopcock with straight bore and one connection with GL thread or ground joint 3-way-stopcock with L-shaped bore and two connections with GL thread. Cylindrical stopcock plug for good tightness, stop valve with mark of flow direction. Suitable for pressures up to max. 6 bar, or for vacuum. Universal chemical resistance, the flowing product is only exposed to PTFE.
Applications
For evacuation of ground joint flasks or distributing liquids or gases. Quick and easy disconnection of flow. Connection of tubing or tubes my means of BOLA Laboratory Screw Joints.
